Stadium Seats
EMIL KIPRIOTIS S.A. is a major manufacturer of
plastic products since 1968. Know-how in combination with the mechanical
equipment of European origin gives us the advantage of excellent
manufacture of thermoplastic products in very competitive prices. Some
indicative customers with requirements of specifications are GREEK
TELECOME, ROMTELECOM, ARMENTEL, SERBIATELECOM, NOKIA, INTRACOM, INFOQUEST
and many others.
 EMIL KIPRIOTIS S.A. is the third company in Europe that has the specific
equipment of thermoplastics’ production of seats under specifications.
Specifically, our company is able to provide you seats from strengthened
plastic, polypropylene or polyamide with the following technical
characteristics:
• Strength of material
• Resistance in percussion
• Anatomic form
• Incombustible
• Durable color in sunlight
Also, direct communication, direct delivery and the favorable terms of
payment in combination with the competitive prices, offer you an
additional profit.
It would be our pleasure to inform you with more details in case you judge
our proposal interesting.
TECHNICAL SPECIFICATIONS OF PLASTIC SEAT
The seat Model EC 2004 is anatomically designed with high rear support. It
has a frictionless surface, it is specifically designed with the essential
slopes and with a central channel for the flow of water in the forward
part without apertures in the seat. Also, it has a special cavity for
numeration board.
Dimensions
W x D x H: 470 x 410 x 350 mm
Width (when he is paraded): 500 mm.
Material
Polypropylene or polyamide.
Colors
Reseda green RAL 6011, dark green RAL 6005, orange RAL 2008, red RAL 3000,
blue RAL 5 005, yellow RAL 1021. And any other colour of your choice.
Placement of Seat
There exist three points of support (two at the seat’s bottom and one
on the front) for better support and resistance in vandalisms. The
placement is usually done directly at the shuttle. In special cases where
there do not exist suitable dimensions, the placement can be done also in
other type of surfaces (ex. metal skeleton). The two apertures at the
seat’s body are not visible via the use of plastic lids.
Design
The form of the seat is with back (ridge) without arms. The seat’s
design is such that it allocates curvy finishing. Moreover the central
channel for the flow and his way of placement do not allow the
accumulation of rain’s water.
Protection - Resistance
• Protection from fire with special FIREPROOF V2. Its resistance in fire
classifies it in the category “difficult ignitable”, according to the
German model DIN 4102 B 1.
• Protection from ultraviolet radiation with the lightproof filter UV.
Guarantee of chromatic stability.
Surface
The surface is frictionless with possibility of easy cleaning, anti-static
for the reject of creation of static charges and also anatomic.
|
|
 |
|
|
|
